CAE Hyper Mesh
CAE Hyper mesh Development training
About This Course
going to start
Course Curriculum
-
Introduction to CAE & HyperMesh Environment
readBasics of FEA & CAE, Industry ApplicationsIntroduction to Altair HyperWorks & GUI NavigationGeometry Import, Model Browser, User ProfilesGeometry cleanup tools – Defeaturing, removing holes, stitching
-
Geometry Cleanup & Topology Editing
readTopology checks – Free edges, Normals, DuplicatesRepair tools – Automeshable geometry, washer creationGeometry morphing basicsPractice session – Full model cleanup exercise
-
1D and 2D Meshing
readConcept of meshing, mesh flow, element quality1D Elements – Bar, Rod, Beam, RBE2, RBE32D Meshing – Manual & Automatic meshing (quads & trias)Mesh cleanup tools, refining mesh, quality checks (Aspect, Jacobian)
-
3D Meshing & Quality Control
read3D Solid Meshing – Tetra and Hexa (auto and manual) Mesh checks – Volume, Warpage, Tetra collapse Mesh editing – Splitting, combining, quality correctionPractical Exercise – Full 3D meshing of a bracket
-
Connectors and Assembly Modeling
readIntroduction to Connectors – Spot, SeamSpot weld realization, bolt connectors, adhesivesAssembly management – organizing model browsers Exercise – Modeling automotive spot weld assembly
-
Material & Property Assignment
readMaterial types – Linear, isotropic, orthotropic Creating properties – Shell, Solid, Beam Card editing – SECSHELL, MAT1, SECBEAM Model preparation for solver deck export
-
Loadcase & Boundary Conditions
readLoads and constraints – SPC, LOAD, FORCE, PRESSURE Load step creation – Static, Modal Load collector organization and management Practice session – Apply loads on automotive part
-
Introduction to Solvers (LsDyna)
readIntroduction to solvers – Linear Static, Modal Exporting solver decks (LsDyna) Error checks, warnings, and debug techniques Basic understanding of solver input file formats
-
Post-processing in HyperView
readIntroduction to HyperView Result visualization – Stress, Displacement, Mode shapes Contour plots, vector plots, animation Report generation basics (screenshot, session files)
-
Final Project & Interview Preparation
readProject assignment – Full CAE preprocessing of real-world part Review & corrections of student projects Resume building for CAE jobs Interview Q&A session, solver basics recap
Course Includes:
-
10 Topics
-
10 Lessons
-
10 Articles
